Lynx Series

The Lynx is a downlight in ELR's Special Craft grade — engineered to the highest standard for applications with a self-contained luminaire. This is the indoor version; the separate Lynx IP Series covers the same optics at IP65. These are linear downlights: a slim profile that sits well in modern interiors, using double optical stages to produce a uniform circular beam with minimal glare. Beam angles range from 18° to 50° — narrow for accent, wide for general wash, with an asymmetric 16° x 36° distribution. Colour temperature in 2700K to 5000K or tuneable white. Rendering in CRI 95 (R9 >50). Specify body in Matt White RAL 9003 or Matt Black RAL 9011. With Trim or Trimless installation.

Fixture Type:

Fixture

Cutout

58 x 36mm (Trim Fix), 62 x 50mm (Trim Tilt), 65 x 40mm (Trimless Fix)

Size

65 x 44mm (Trim Fix), 76 x 64mm (Trim Tilt), 56 x 33mm (Trimless Fix)

Beam Angle

18°, 29°, 50°, 16° x 36°

LED Module & Driver

CRI

ProART (Ra 95, R9 >50)

Delivered Lumens

360lm - 440lm

System Power

4W

CCT

Single CCT

LYNX 2 LINEAR

Technology and Feature

ComfyEYE ComfyEYE
ProART ProART

Driver

Non-Dim Non-Dim
Phase Phase
0-10V 0-10V
DALI DALI

Fixture

Colour Options

Colour

Matt White RAL 9003

Matt White RAL 9003

Matt Black RAL 9011

Matt Black RAL 9011

Colour Temp

5000K

5000K

4000K

4000K

3500K

3500K

3000K

3000K

2700K

2700K

Beam Angle

50°

50°

29°

29°

18°

18°

16° x 36°

16° x 36°
